GLENMAGGIE

Name	GLENMAGGIE
Secondary Dam	No
Main Dam
Reservoir Name	GLENMAGGIE
Purposes	I - irrigation,H - hydroelectric
Owner/Operator Name	Southern Rural Water
Consultant Name	State Rivers & Water Supply Commission, Victoria
Contractor Name	State Rivers & Water Supply Commission, Victoria
Comment One
Comment Two
URL	https://en.wikipedia.org/wiki/Glenmaggie_Dam
PSP
Electrical Power (MW)	4
Mean Annual Energy (GWh)	9
Resettlement

Alternative Name
National Code
Dam Code	I00900081
Nb References ICOLD	1
References ICOLD	Timothy Mote, Manuel G. de Membrillera Ortuño (2025). WILDFIRE IMPACT ON DAM AND RESERVOIR LANDSLIDE SAFETY RISKS CONSIDERING FUTURE CLIMATE / Impact des incendies de forêt sur les risques liés à la sécurité des barrages et des réservoirs, compte tenu du climat futur. 28th Congress of ICOLD-CIGB. Chengdu, China. CRC Press
Reserved Committee O

Built	1927
Particular
Dam Type	PG
Sealing	fc
Foundation	R
Height (m)	37.0
Length (m)	293.0
Spillway Capacity (m³/s)	2775.0
Spillway Type	V
Detailed Type of Dam	GCC - gravity dam in conventional concrete,BM - barrage
Elevation (m)	79.55

Volume Dam (1,000m³)	15595
Reservoir Volume (1,000m³)	190410
Reservoir Area (1,000m²)	17600
Reservoir Length (km)
Catchment (km²)	1900.0
Irrigated Area (km²)	530.0
Flood Protect (% of reservoir volume)
Sedimentation	0.05
Reservoir Code	R00900081
Reservoir ISO 3166	AU
